780nm~785nm Fiber Coupled Laser Diode (LD)

785nm Fiber Coupled Laser Diode

Wavespectrum Laser, Inc.

4w~5w 780nm Fiber Coupled Laser Diode Module

WSLB-785-004-H

Parameter

Symbol

Value

Unit

Reverse Voltage

V_r

2.0

V

Operating Temperature

T_op

-10~+30

°C

Storage Temperature

T_stg

-40 ~ +85

°C

Leadsoldering temperature

T_is

260

°C

Features

Applications

         785nm laser diode

         4.5W output power

         P2 package

         TEC Cooling

         Medical laser treatment

         Pumping

Specifications

WSLB-785-004-H

Center Wavelength@25℃

780+/-10 nm

Spectral Width (FWHM)

3nm

Output Power

4.5W

Temperature Coefficient of Wavelength

0.3nm / °C

Slope Efficiency

1.0mW/mA

Threshold Current (Typ.)

0.3A

Operating Current (Typ.)

2.5A

Operating Voltage

7V

Thermistor Value(25°C)

----

TEC Current (Max)

----

TEC Voltage( Max)

----

Fiber Core

<300um

Fiber N.A.

0.22

Fiber Length

100cm

Bend Radius(Min)

25mm

Connector Type

ST/FC/SMA905

Cooling

TEC Cooling

Aiming Beam

Optional

Package Style

----

P2

----
