| Wavelength: |
1) with SM/PM Fiber
2) 3-Channel Output
3) Built-in TEC Cooling
4) High Power Stability
5) Collimation Optional
6) Offer OEM Product
Specifications
|
WSLS-405-3C-015m-4
|
||
|
|
Min |
Type |
Max |
|
Center Wavelength@25℃ |
400nm |
405nm |
415nm |
|
Output Power adjustment range |
15mW |
||
|
Fiber Core |
4um SM fiber |
||
|
Output Channels Number |
3 channels |
||
|
Operating Temperature |
0~50 °C |
||
|
Long Term Power Stability |
---- |
2% |
---- |
|
Temperature Stability |
---- |
0.01°C |
---- |
|
Noise (p-p) (20Hz to 2MHz) |
---- |
2% |
---- |
|
RMS Noise (20Hz to 2MHz) |
---- |
0.2% |
---- |
|
Fiber Connector |
FC/ST/SMA905 |
||
|
Fiber Length |
---- |
80cm |
100cm |
|
DC Power Supply |
5V±0.1V, Ripple<25mVp-p, < 2A |
||
|
TTL modulation |
10MHz |
||
|
Collimation |
Optional |
||
|
Cooling |
TEC Cooling |
||
|
Protection |
(1)Reverse polarity and transient/ESD, (2)over temperature and LED pre-failure indicator, (3)interlock |
||
Wavespectrum Laser, inc. can offer Customized (OEM) Fiber Coupled 3-Channel Diode Laser System
- Customized Wavelength
- Customized Channel NO.
- Customized Output Power
- Customized Fiber Type (SM/PM/MM)
- Cutomized Modulation Frequency
Please contact us with info@wavespectrum-laser.com
Wavespectrum Laser, Inc. offer-----
Custom-built Fiber Coupled Laser System!
l Custom-built Fiber: SM/MM/PM Fiber
l Custom-built Wavelength：375nm~1600nm
l Custom-built Output Power
l Custom-built Channel:1/2/3/……
l Modulation Optional
l Collimation Optional
