| Wavelength: |
1) 405nm-635nm-650nm 3-Wavelength Output
2) 3-Channel Output
3) Built-in TEC Cooling
4) Modulation Optional
5) Customized Wavelength/Output Power/Channel
Specifications
|
WSLS-A-3C-010m-4
|
|||
|
|
Channel 1 |
Channel 2 |
Channel 3 |
|
|
3 Channels Wavelength@25℃ |
405nm |
635nm |
650nm |
|
|
Output Power |
10mW |
10mW |
10mW |
|
|
Fiber Core |
4um SM fiber |
|||
|
Output Channels Number |
3 channels |
|||
|
Operating Temperature |
0~50 °C |
|||
|
Long Term Power Stability |
2% |
|||
|
Temperature Stability |
0.01°C |
|||
|
Noise (p-p) (20Hz to 2MHz) |
2% |
|||
|
RMS Noise (20Hz to 2MHz) |
0.2% |
|||
|
Fiber Connector |
FC/ST/SMA905 |
|||
|
Fiber Length |
---- |
80cm |
100cm |
|
|
DC Power Supply |
5V±0.1V, Ripple<25mVp-p, < 2A |
|||
|
TTL modulation |
10MHz |
|||
|
Collimation |
Optional |
|||
|
Cooling |
TEC Cooling |
|||
|
Protection |
(1)Reverse polarity and transient/ESD, (2)over temperature and LED pre-failure indicator, (3)interlock |
|||
Wavespectrum Laser, Inc. offer-----
Custom-built Fiber Coupled Laser System!
l Custom-built Fiber: SM/MM/PM Fiber
l Custom-built Wavelength：375nm~1600nm
l Custom-built Output Power
l Custom-built Channel:1/2/3/……
l Modulation Optional
l Collimation Optional
